CONTEC 1200G, Twelve Channel ECG Machine
HS1599
Free shipping
Save 42%
Hover on image to enlarge
Our advantages
- — 12 months warranty
- — SMS notification
- — Return and exchange
- — Different payment methods
- — Best price
Payment options
Delivery
Find similar items here
Please sign in so that we can notify you about a reply
Description
Contec ECG Machine 1200G, 12Channel ECG Machine Descriptions :
ECG1200G is an electrocardiograph which can collect 12-lead ECG signal simultaneously and print ECG waveform with thermal printing system. It features in, recording and displaying ECG waveform in AUTO/Manual mode, measuring and diagnosing ECG waveform parameters automatically, prompting for “Lead off” and “Lack of paper”, multi-language interface, AC/DC, selecting rhythm lead, printing the trend chart and histogram of P-R interval, case database management.
ECG1200G is an electrocardiograph which can collect 12-lead ECG signal simultaneously and print ECG waveform with thermal printing system. It features in, recording and displaying ECG waveform in AUTO/Manual mode, measuring and diagnosing ECG waveform parameters automatically, prompting for “Lead off” and “Lack of paper”, multi-language interface, AC/DC, selecting rhythm lead, printing the trend chart and histogram of P-R interval, case database management.
Performance :-
-
Input mode: floating and defibrillation protection
-
Frequency response: 0.05Hz ~ 150Hz(-3dB~+0.4dB)
-
CMRR: >60dB, >100dB(add filter)
-
Time constant:≥ 3.2s
-
Patient leak current: <10µA
-
Calibration voltage: 1mV
-
Sensitivity: 2.5, 5, 10, 20, 40 mm/mV ±5%, standard sensitivity: 10mm/mV±2%
-
Noise level: ≤15µVp-p
-
Input circuit current: ≤50nA
-
Input impedance: ≥50MΩ
-
Sampling accuracy: 12-bit
-
Safety classification: class I, type CF and defibrillation-proof applied part
-
Recording mode: thermal printing system
-
Paper size: 210mm(W)×20m(L)
-
Sampling frequency: 1000Hz
-
EMG interference filter: 25Hz/35Hz (-3dB)
-
Power frequency filter: AC 50Hz/60Hz(-20dB)
- Auto: 25, 50mm/s, ±5%
-
Rhythm: 25, 50mm/s, ±5%
-
Manual: 5, 6.25, 10, 12.5, 25, 50mm/s, ±5%
-
Auto record: set record according to auto record format and mode, automatically switching leads, measuring and analyzing.
-
Rhythm record: set record according to rhythm record format and mode, automatically measuring and analyzing.
-
Manual record: set record according to record format, manually switching leads.
-
Measurement parameters: HR, P-R interval, P Duration, QRS Duration, T Duration, Q-T interval, Q-Tc, P Axis, QRS Axis, T Axis, R(V5), S(V1), R(V5)+S(V1)
-
Power supply:
-
AC: 100V~240V(50/60Hz)
-
DC: 14.8V/3500mAh rechargeable lithium battery
-
Fuse specification: two AC time lag fuse(φ5×20mm), T1.6AL250V
-
Waterproof degree: IPX0
-
Working mode: continuous working
List of Supply with ECG Machine :-
1. ECG Cable 1 No.
2. Bulb Electrode 1 Set
3. Clamp Electrode 1 Set
4. Power Cable 1 No.
5. Earthing Cable 1 No.
6. User Mannual 1 No.
Features
Estimated Delivery:
5-10Days
Warranty :
- 1 Years
Product Specifications
ECG Channel Print:
- 12 Channel
Machine Operation :
- Up-Down Button
Measurement /Interpretation :
- Measurement
- Automatic Interpretation
Printer /Recorder:
- Inbuilt Thermal Printer
Printing Paper Type & Size:
210mm(W)×20m(L)
Recording Mode:
- Auto Mode
- Manual
- Rhythm
Brand/Manufacturer
Brand:
Contec
Weight & Dimensions
Product Dimension (mm):
340mm × 320mm× 85mm
Product Weight:
3.2Kg
Memory and Storage
Storage :
300 Reports
Power Supply & Battery
AC input voltage:
100-240 V
Battery capacity:
3500mAh
Battery type:
Lithium Ion rechargeable
